C-17- The C-17 Globemaster III is the most flexible cargo aircraft to enter the airlift force. The C-17 is capable of rapid strategic delivery of troops and all types of cargo to main operating bases or directly to forward bases in the deployment area. The aircraft can perform tactical airlift and airdrop missions and can transport litters and ambulatory patients during aeromedical evacuations. The inherent flexibility and performance of the C-17 force improve the ability of the total airlift system to fulfill the worldwide air mobility requirements of the United States.

305th Air Mobility Wing
The mission of the 305th Operations Group is to deploy worldwide from America's Eastern Gateway, to perform aerial refueling and airlift, in support of tactical, strategic, reconnaissance, transport, and bombardment forces in high-threat and chemical warfare environments. The group is comprised of the 2nd Air Refueling Squadron, 6th Airlift Squadron, 32nd Air Refueling Squadron, 911th Air Refueling Squadron, and the 305th Operations Support Squadron. The group flies the C-17 Globemaster III and KC-46A Pegasus in support of worldwide operations.

Technical Details

General Characteristics
Primary Function: Cargo and troop transport
Prime Contractor: Boeing Company
Power Plant: Four Pratt & Whitney F117-PW-100 turbofan engines
Thrust: 40,440 pounds, each engine
Wingspan: 169 feet 10 inches (to winglet tips) (51.75 meters)
Length: 174 feet (53 meters)
Height: 55 feet 1 inch (16.79 meters)
Cargo Compartment: length, 88 feet (26.82 meters); width, 18 feet (5.48 meters); height, 12 feet 4 inches (3.76 meters)
Speed: 450 knots at 28,000 feet (8,534 meters) (Mach .76)
Service Ceiling: 45,000 feet at cruising speed (13,716 meters)
Range: Global with in-flight refueling
Crew: Three (two pilots and one loadmaster)
Aeromedical Evacuation Crew: A basic crew of five (two flight nurses and three medical technicians) is added for aeromedical evacuation missions. Medical crew may be altered as required by the needs of patients
Maximum Peacetime Takeoff Weight: 585,000 pounds (265,352 kilograms)
Load: 102 troops/paratroops; 36 litter and 54 ambulatory patients and attendants; 170,900 pounds (77,519 kilograms) of cargo (18 pallet positions)
Unit Cost: Unit Cost: $202.3 million (FY98 constant dollars)
Date Deployed: June 1993
Inventory: Active duty, 134; Air National Guard, 8; Air Force Reserve, 8
